Chipset:
Chord Electronics custom coded Xilinx Artix 7 (XC7A15T) FPGA
Tap-length:
49,152
Pulse array:
10 element pulse array design
Frequency response:
20Hz – 20kHz +/- 0.2dB
Output stage:
Class A
Output impedance:
0.025Ω
THD:
<0.0001% 1kHz 3v RMS 300Ω
THD and noise at 3v RMS:
120dB at 1kHz 300ohms ‘A’ wighted (reference 5.3v)
Noise 2.6 uV ‘A’ weighted:
No measurable noise floor modulation
Signal to noise ratio:
126dB ‘A’ Weighted
Channel separation:
135dB at 1kHz 300Ω
Power output @ 1kHz 1% THD:
94mW 300Ω
740mW 32Ω
1050mW 8Ω
Weight:
450g
Dimensions:
2.3cm (H) 10cm (W) 13.1cm (D)
